Tianjin FYH bearing, special bearing FYH, FYH bearing factory direct sales, wholesale, FYH bearing FYH bearing authority. FYH bearing company, founded in 1950, specializing in the production of PILLOW BLOCK (arrange ushering rolling bearing), has now become a world-class arrange ushering bearing manufacturers. With advanced technology, using unique automatic self-aligning bearing manufacturing production line, from the quality inspection of fully automated. FYH arrange ushering bearing tolerance than Japanese industrial products specifications strictly, can be rotating at high speed using various demanding places. About 700 kinds of standard bearing FYH, about 300 kinds of FYH housings. Composed of thousands of bearing components from industry made a great contribution. In addition to the standard products, and heat resistance, corrosion resistance, dustproof, etc can withstand a variety of harsh environments FYH arrange ushering rolling bearing. In order to meet the requirements of customer diversity, FYH assembled small light weight bearing components, stainless steel series, ceramic series and other components, and the parties to get the praise.
2 product model insert spherical bearing FYH production from light load to heavy load widely covered areas, to meet the diverse needs of the world industry. Arrange ushering rolling bearing is deep groove ball bearing and all kinds of grease seal type bearing box in the shape of a combination of high precision components products. Arrange ushering rolling bearing can be achieved by several bolts installed directly to the mechanical device's main body, with automatic tuning of mind Can, can be the supplement of the grease, etc., is a product installation, use is Jane. Including the UCP contains, UCF, UCFL, UCT and UCPA products. Stamping steel plate series bearing components. The outer spherical bearing components, including UC, B, KH, UK series products.
3 product characteristics: high load ability and precision
Internal structure and single row deep groove ball bearings are the same. Under a lot of radial load at the same time, can withstand axial load in two directions.
Bearing the same precision and the accuracy of general, and has a high rotation precision and good high speed performance
FYH bearing
2: the reasonable structure of the heart and the most suitable match
The bearings and bearing components through ball diameter with spherical inner hole and a self-aligning bearing performance. [1] therefore, can be adjusted due to the deflection of shaft, eccentric axis deviation, such as is not abnormal load on the bearing, thus ensuring the service life of bearing was.
The globule outer diameter of the bearing surface after grinding, and the spherical inner hole of the bearing also boring machine again after precision machining, so the bearing and the bearing seat of best fit at the same time, to send back to high performance.
3: high sealing performance
Bearing components due to install the sealing ring in the bearing outer ring and bearing inner ring on the installation of the multiplier effect of the oil slinger and can priority placed inside the bearing lubricating oil leak outward, and placed outside of the dust, such as water bearing inside.
Seal for oil resistant performance of synthetic rubber, sealing ring of the lips with the best pressing force and the bearing inner ring.
In the dust, the more used in the use of such as water, triple seal components (L3) or with dust cover components (C, CD, FC, FD) is the best.
4: added grease simple
Bearing grease injection nozzle are installed on, so can be very convenient to the running of the bearing grease. In the dust, water, moisture, harsh environments, such as high temperature, when using regular fresh grease, to ensure the bearing is in the best condition, so as to prolong the life of bearing.
Five: high rigidity, high strength of bearing seat
Bearing the relieve depression caused by stress concentration and load deformation of optimum design, and choose the high quality materials by high level of casting technology and punching processing technology of production.
High rigidity, high strength of bearing seat makes the bearing will not effect on abnormal load and prolong the service life of bearing. In addition, blue paint spraying the surface of bearing, so can keep the appearance of the beautiful for a long time.
Six: install and easy to use
Various kinds of bearing components, can pass several bolts directly to the mechanical installation, the themes of the device, and in this state use directly. In principle, in addition the bearing inner ring of the shaft by clearance fit.
4 fyh bearing suffix code meaning L3 (triple seal component is in the steel seal plate with triple lip stick on the oil seal can effectively prevent the dust and mud into the bearing internal has good dustproof function) of the dust cover attached code C D FC and FD, which is suitable for tandem type D type and C type D FD type belongs to the side seal type and vertical bearing CD FCD model used in high temperature component tag for D1K2 D9K2 D2K2 and used in low temperature, including D9K2 used for high temperature bearing using fluorine grease highest use temperature is 250 ℃. [2] used in high-speed bearing FYh bearing marked as K3 can achieve high speed and low fever, and the purpose of the low torque, commonly used in fiber machinery printing machinery requirements at high speed and low torque environment of low fever. Special blower bearing markers for S5, stainless steel series marked as s6. There are also some affiliate code said to cooperate:
J: it means the diameter of the bearing box of ball bearing for J7 tolerance zone
H: it means the diameter of the bearing box of ball bearing for H7 tolerance zone,
K: it means the diameter of the bearing box of ball bearing for K7 tolerance zone;
Grease the code:
D1 said SH44M lubrication,
D2 said SH33M lubrication,
D9 said fluorine grease lubrication;
Said method is set screw
G4: pointed screw,
G6: pin screw at the top,
The G7: take the nylon screw loose;
The representation method of oil seal:
K2: silicone rubber sealing ring,
K3: non-contact seal.
Seal logo:
P3: no oil, no oil slinger
P4: without oil seal;
Thread the bearing box of injection nozzle aperture representation and meaning:
A1: PT1/8 pipe thread,
A2: PF1/8 pipe thread,
A3: PT1/4 pipe thread,
A4: PF1/4 pipe thread;
The representation method of injection nozzle position and significance:
B1: the right side of the oil hole,
B2: on the left side of the oil hole,
B3:45 degrees of oil injection hole,
B5:30 degrees oil injection hole,
B7: left and right sides of the oil hole;
The method and purport of bearing seat contour machining said:
E1: steel or cast iron cover installation groove,
E3: cast iron groove installation,
E4: no oil type bearing box; Bearing box material symbol and meaning
H1: stainless steel castings,
H5: general rolled steel structure,
