NSK precision angular contact ball bearings, with different options can be selected according to the best specifications of a variety of products, the most suitable for the spindle and other rotating body vibration requirements of high precision, fast speed of use.

Vertical equipment composition views Results words views Results Results



The product lineup consists of a basic series from ISO specifications to a dedicated series for machine tools.

Has been filled with grease, with a ring of angular contact ball bearings have been formed series.

High-performance series Robust bearings, a strong lineup of products, ranging from high-rigidity series to ultra-high-speed products.

High precision angular contact ball bearings (standard series)

This is the ISO standard NSK precision angular contact ball bearings of the basic series.

Features:

Long life bearing steel (Z steel) as a standard material.

70 series, 79 series of products, but also with the ring, so that grease life increased to 1.5 times.

Depending on the type, there are two types of retainers.

High precision angular contact ball bearings (standard series)



High-speed angular contact ball bearings (Robust series)

This is the NSK set of proud of the material technology, evaluation technology and the essence of analytical technology developed support for high-performance high-performance machine tool products. In addition, with a series of products with high performance and long life characteristics, can improve the reliability of machine tools, and environmental performance, and can contribute to energy conservation.

Features:

High-speed angular contact ball bearings (Robust series)

Low heat, high speed.

The use of heat and abrasion resistance of the excellent SHX material production of X-type products, to achieve a high speed, long life.

According to different uses, established a different contact angle and ball material specifications of the powerful product lineup.

Bandwidth sealing ring, compared with open bearings, grease life increased to 1.7 times, to achieve a long life.



High-speed angular contact ball bearings (Robust series SpinShot Ⅱ)

The pursuit of refueling optimization, to achieve an unprecedented mute at the same time, to achieve a further high speed.

Features:

High-speed angular contact ball bearings (Robust series SpinShot Ⅱ)

Using oil and gas lubrication, in the NT # 40 level, to achieve 40000 per minute turn.

Compared with the previous oil and gas lubrication, reduce the noise of about 3 ~ 5dB.

Only about 1% of the previous oil and gas lubrication, that is, to reach the speed of 40000 revolutions per minute.



High precision angular contact ball bearings (BGR series)

This is a high-function series that can match the high-precision, ultra-high-speed rotation of the small shaft with a small diameter of 30mm.

Features:

High precision angular contact ball bearings (BGR series)

For the small axis of the design of ultra-high-speed bearings.

The use of heat and abrasion resistance of the excellent SHX material production of X-type products, to achieve a high speed, long life.

Standard uses high-precision specifications.



High-speed thrust angular contact ball bearings (Robust series)

Robust series is used to withstand the thrust of the angular contact ball bearings, to achieve high speed and high rigidity.

Features:

High-speed thrust angular contact ball bearings (Robust series)

BTR contact angle 40 °: high thrust rigidity and low heat generation both.

BAR contact angle of 30 °: compared with the BTR, pay more attention to high-speed.



High Rigidity Axial Angular Contact Ball Bearings (TAC-F Series)

The TAC-F series is an angular contact ball bearing series with high rigidity for thrust thrust.

Features:

Contact angle 50 °: relative to high speed more attention to rigid. Ideal for strong cutting and high rigidity.

Non-separation type, good operability.
