Four point contact ball bearings are radial single row angular contact ball bearings, the raceway used to support the role of the axial load in both directions. For specified axial loads, a limited radial load (→ bearing configuration design, load ratio) can be supported. This type of bearing compared with the double row bearing, occupying the axial space significantly reduced.
figure 1
The inner ring is separated from the inner ring. This allows a greater number of balls to be loaded into the bearing, giving the bearing a higher load bearing capacity. The bearing is a separate design, that is, with the ball and cage components of the outer ring can be installed with two inner ring half ring.
SKF explorer four-point contact ball bearing double semi-inner ring with a groove of the shoulder. When used in conjunction with cylindrical roller bearings, the flow of oil is improved. In addition, the recessed portion can also be used for disassembly.
figure 2
The standard supply range for SKF four-point contact ball bearings includes QJ 2 and QJ 3 series bearings.
Uss Copyright compositions.KSKSKSKSKS advert
According to the different design, series and size, the SKF four point contact ball bearing is equipped with a cage in Table 1.
For more information on the application of the cage, see the cage and cage material.
Positioning slot
SKF four-point contact ball bearings can be configured in the outer ring positioning slot, to prevent rotation (model suffix N2). The position of the positioning groove is 180 °. The dimensions and tolerances of the positioning grooves are in accordance with ISO 20515: 2012, as listed in Table 2.
